Description
Description
ESS ES9039Q2M SABRE® DAC
Stereo RCA audio output
Optical, coaxial, and USB audio outputs
Two programmable quick-touch presets
DSD playback
Additional streaming via AirPlay 2, Spotify Connect and TIDAL Connect
Roon Ready
Two-way aptX™ Adaptive* Bluetooth
Specification
Finish:
Black: Matte Satin Paint
Version:
N030
Product Weight:
0.57kg / 1.26lbs
Mounting:
Bottom-panel keyhole slot
Product Dimensions:
143 x 36 x 143mm (W x H x D)
5.6 x 1.4 x 5.6 in (W x H x D)*
*Non-metric measurements are approximate.
Included Accessories:
• USB Power Supply
• 4x International Plug Adapter
• USB-C Power Cable
• Stereo RCA to RCA Cable
• Ethernet Cable
• Safety/Warranty Guide
• Quick Setup Guide
Storage Environment:
-10°C to 50°C, 20% to 80% relative humidity
Status Indicator:
LED
Volume Control Buttons:
Touch LED
Play/Pause Button:
Touch LED
Preset Buttons:
Touch LED x 2
Power Supply:
USB-C (5V-2A)
Optical/Analog Input:
IR Sensor Built In - front panel with IR Remote Learning
Coaxial Output:
RCA
Ethernet/LAN:
Ethernet RJ45, Gigabit 1000 Mbps
IR Input:
3.5mm Jack
Optical Output:
TOSLINK digital optical
Wi-Fi Built In:
Wi-Fi 5 (802.11ac), dual-band
USB IN:
Type A (Fat32 Formatted) - External Storage only; Local Server Mode
Trigger Out:
12 Volt
Bluetooth Quality:
Bluetooth 5.2 aptX Adaptive
Audio Output:
Analog RCA Stereo with Fixed option; USB Audio 2.0 (Type A)
Headphone Output:
Bluetooth
Bluetooth Connectivity:
Two-Way (transmit & receive)
Subwoofer Output:
Wireless to PULSE SUB+
Operating System:
BluOS
Supported Network File Sharing:
Server Message Block (SMB) up to 200,000 files
3rd-Party Integrations:
AirPlay 2, Spotify Connect, Tidal Connect, Roon Ready
App Controller Operating System:
iOS, Android, Windows, macOS
Album Art Supported:
JPG, PNG
Control System Integrations:
Crestron, Control4, RTI, ELAN, URC, Lutron
Processor
ARM® Cortex™ -A53, Quad-Core, 1.8GHz per core
Music Services & Internet Radio:
23+
Music Services
Internet Radio
Voice Control Integrations:
Amazon Alexa Skills
Supported Audio File Formats:
MP3, AAC, WMA, WMA-L, OGG, ALAC, OPUS
Native Sampling Rates:
up to 192 kHz
DAC:
ESS ES9039Q2M
Supported High-Quality Audio File Formats:
FLAC, MQA, WAV, AIFF, MPEG-4 SLS
Bit Depth:
16-24
Signal-to-Noise Ratio:
-118 dB
DSD Support:
DSD256
Audio Controls & EQ:
BluOS Controller App
Distortion:
THD+N, 0.0007%
