McIntosh MC2301 1-Channel Vacuum Tube Amplifier

ELECTRONIC SPECIFICATIONS
Power Output per Channel - 300W @ 2, 4 or 8 Ohms
Number of Channels - 1
Total Harmonic Distortion - 0.5% maximum harmonic distortion at any power level from 250 milliwatts to rated power, 20Hz to 20,000Hz
(≤ 0.25% harmonic distortion at 1kHz)
S/N below rated output - 117dB
Dynamic Headroom - 1.2dB
Damping Factor - >15 Wideband
Rated Power Band - 20Hz to 20kHz
Frequency Response, +0, -0.5dB from 20Hz to 20,000Hz, +0, -3.0dB from 10Hz to 100,000Hz

CONTROL
Remote Power Control - Yes
Multi-Channel DB25 Cable - N/A

GENERAL SPECIFICATIONS
Circuit Configuration - Quad Balanced, Unity Coupled
Circuit Design - Vacuum Tube
Mono Bridge - No
Mono Parallel - No
Output Type - Unity Coupled Output Transformer
Meters - Yes
Meter Light Switch - Yes
Balanced Input - Yes
Front Panel - 1/2" Glass with handles
Illumination - LED Fiber Optic
Chassis Style - Open Stainless Steel

CONNECTIVITY
Speaker Binding Post Type - Yes, 200 amp, 3-way

WEIGHTS & DIMENSIONS
Unit Dimensions (W x H x D) - 17-3/4" (45.09cm) x 12-5/16" (31.27cm) (including feet) x 23" (58.42cm) (including front panel and cables)
Unit Weight - 116 lbs (52.6 kg)
Shipping Weight - 141 lbs (63.9 kg)
