The Wisdom Audio Series LS3i is a 60-inch planar-magnetic line-source loudspeaker for in-wall installation — designed to sit behind an acoustically transparent screen and deliver reference cinema and music with output in excess of 127dB.
The Wisdom Series LS3i is a full-size planar-magnetic line-source loudspeaker built for architectural installation. It is a statement design — a 60-inch planar line source engineered to deliver reference-grade sound as a main channel or surround, most often installed behind an acoustically transparent projection screen in a dedicated cinema or high-end media room.
This is a large in-wall loudspeaker, measuring 64.7 × 23.75 × 12 inches (164.3 × 60.3 × 30.5 cm) and weighing 200 lb (90 kg), so it is designed into the room’s construction. It is available in custom colours and, being intended to sit behind a screen or grille, is engineered to be heard rather than seen.
A single LS3i can reproduce sound pressure levels in excess of 127dB at 12 feet, with a quoted frequency response of 80Hz–20kHz (±3dB) and a sensitivity of 98dB (2.83V/1m). The 60-inch line source distributes sound evenly across the width of the room and reduces floor and ceiling reflections, giving consistent level and clarity from front to back.
The LS3i is a two-way design built on a 60-inch planar-magnetic line source. It requires two channels of amplification and an outboard active crossover with DSP, so its response can be tailored precisely to the installation. Its ability to play behind an acoustically transparent screen makes it a natural reference choice for serious cinema.
A line source radiates as a tall, narrow wavefront, which falls off more slowly with distance than a point source and largely avoids strong floor and ceiling reflections — giving even coverage across a large room. Wisdom’s planar-magnetic thin-film drivers add the low-mass speed, detail and freedom from compression that define the brand, controlled by the required outboard DSP.
Type: two-way planar-magnetic line-source in-wall loudspeaker. Driver: 60-inch planar-magnetic line source. Frequency response: 80Hz–20kHz (±3dB). Sensitivity: 98dB (2.83V/1m). Maximum SPL: in excess of 127dB at 12 ft. Impedance: 5.6 ohms (both sections). Amplification: two channels required. Processing: outboard active crossover with DSP required. Dimensions: 64.7 × 23.75 × 12 in. Weight: 200 lb (90 kg). Finish: custom colours.
The LS3i is for the dedicated home cinema or reference music room where nothing but full-scale, reference performance will do — ideally installed behind an acoustically transparent screen. It is a designed-in component, and pricing is on application to suit the specification.
A line-source system of this scale must be engineered into the room from the outset — construction, amplification, DSP, screen and acoustics all matter. We design, supply and install Wisdom cinema systems across the South, integrating them with projection, processing and control so they perform at reference. Speak to our team to discuss your project.
